Samsung
Samsung Galaxy Z Fold5
| NETWORK | Technology | GSM / CDMA / HSPA / EVDO / LTE / 5G | |
| LAUNCH | Announced | 2023, July 26 | |
| Status | Available. Released 2023, August 11 | ||
| BODY | Dimensions | Unfolded: 154.9 x 129.9 x 6.1 mm | |
| Folded: 154.9 x 67.1 x 13.4 mm | |||
| Weight | 253 g (8.92 oz) | ||
| Build | Glass front (Gorilla Glass Victus 2) (folded), plastic front (unfolded), glass back (Gorilla Glass Victus 2), aluminum frame | ||
| SIM | Nano-SIM and eSIM or Dual SIM (2 Nano-SIMs and eSIM, dual stand-by) | ||
| IPX8 water resistant (up to 1.5m for 30 min) | |||
| Armor aluminum frame with tougher drop and scratch resistance (advertised) | |||
| Stylus support | |||
| DISPLAY | Type | Foldable Dynamic AMOLED 2X, 120Hz, HDR10+ | |
| Size | 7.6 inches, 183.2 cm2 (~91.1% screen-to-body ratio) | ||
| Resolution | 1812 x 2176 pixels (~373 ppi density) | ||
| Cover display: | |||
| Dynamic AMOLED 2X, 120Hz, Corning Gorilla Glass Victus 2 | |||
| 6.2 inches, 904 x 2316 pixels, 23.1:9 ratio | |||
| PLATFORM | OS | Android 13, One UI 5.1.1 | |
| Chipset | Qualcomm SM8550-AC Snapdragon 8 Gen 2 (4 nm) | ||
| CPU | Octa-core (1x3.36 GHz Cortex-X3 & 2x2.8 GHz Cortex-A715 & 2x2.8 GHz Cortex-A710 & 3x2.0 GHz Cortex-A510) | ||
| GPU | Adreno 740 | ||
| MEMORY | Card slot | No | |
| Internal | 256GB 12GB RAM, 512GB 12GB RAM, 1TB 12GB RAM | ||
| UFS 4.0 | |||
| MAIN CAMERA | Triple | 50 MP, f/1.8, 23mm (wide), 1.0µm, Dual Pixel PDAF, OIS | |
| 10 MP, f/2.4, (telephoto), PDAF, OIS, 3x optical zoom | |||
| 12 MP, f/2.2, 123˚, 12mm (ultrawide), 1.12µm | |||
| Features | LED flash, HDR, panorama | ||
| Video | 8K@30fps, 4K@60fps, 1080p@60/240fps (gyro-EIS), 720p@960fps (gyro-EIS), HDR10+ | ||
| SELFIE CAMERA | Single | 4 MP, f/1.8, 26mm (wide), 2.0µm, under display | |
| Cover camera: | |||
| 10 MP, f/2.2, 24mm (wide), 1/3", 1.22µm | |||
| Features | HDR | ||
| Video | 4K@30/60fps, 1080p@30/60fps, gyro-EIS | ||
| SOUND | Loudspeaker | Yes, with stereo speakers | |
| 3.5mm jack | No | ||
| 32-bit/384kHz audio | |||
| Tuned by AKG | |||
| COMMS | WLAN | Wi-Fi 802.11 a/b/g/n/ac/6e, tri-band, Wi-Fi Direct | |
| Bluetooth | 5.3, A2DP, LE, aptX HD | ||
| Positioning | GPS, GLONASS, GALILEO, BDS | ||
| NFC | Yes | ||
| Radio | No | ||
| USB | USB Type-C 3.2, OTG | ||
| FEATURES | Sensors | Fingerprint (side-mounted), accelerometer, gyro, proximity, compass, barometer | |
| Bixby natural language commands and dictation | |||
| Samsung DeX (desktop experience support) | |||
| Samsung Pay (Visa, MasterCard certified) | |||
| Ultra Wideband (UWB) support | |||
| BATTERY | Type | Li-Po 4400 mAh, non-removable | |
| Charging | 25W wired, 50% in 30 min (advertised) | ||
| 15W wireless | |||
| 4.5W reverse wireless | |||
| MISC | Colors | Icy Blue, Phantom Black, Cream, Gray, Blue | |
| Models | SM-F946B, SM-F946B/DS, SM-F946U, SM-F946U1, SM-F946N, SM-F946W, SM-F9460 | ||
| SAR | 1.16 W/kg (head) | ||
| SAR EU | 1.24 W/kg (head) 1.19 W/kg (body) | ||
| TESTS | Performance | AnTuTu: 1250358 (v9), 1519358 (v10) | |
| GeekBench: 4824 (v5.5), 5396 (v6.0) | |||
| GFXBench: 65fps (ES 3.1 onscreen) | |||
| Display | Contrast ratio: Infinite (nominal) | ||
| Camera | Photo / Video | ||
| Loudspeaker | -25.9 LUFS (Very good) | ||
| Battery life | Endurance rating 95h |
